GH800

GH800 High Expansion Generator

“GH800″ high expansion foam generator, 710 l @ 4 bar, 3” PN16 flange or 88.9 mm grooved connection, carbon steel painted or stainless steel 316 painted pipe, stainless steel 316 body

• CNBOP and ÉMI certified to EN13565-1

GH800 “GH800″ high expansion foam generator, 710 l @ 4 bar, 3” PN16 flange or 88.9 mm grooved connection, carbon steel painted or stainless steel 316 painted pipe, stainless steel 316 body

• CNBOP and ÉMI certified to EN13565-1

Documents & Resources (2)

Download all documents

Download selected files (1)

Add to download box (1)
All resources (1)
technical documentation (1)

Foam Systems

Product sheet

Language:

Languages

Click to select other languages
Please select one language
Downloads are not available for youtube, video and external files

Product Variants

move right table move right table

move right table

move left table

move left table move left table

  • SAP number EGH800D
  • Connection Flange
  • Size 3″/DN80
  • Finish Body: Natural | Pipe: Flame red RAL3000
  • Main material Body: Stainless steel 316 | Pipe: Carbon steel
  • Style Fixed
  • Nominal flowrate 710 @ 4 bar
  • SAP number EGH800DS
  • Connection Flange
  • Size 3″/DN80
  • Finish Body: Natural | Pipe: Flame red RAL3000
  • Main material Body: Stainless steel 316 | Pipe: Stainless steel 316
  • Style Fixed
  • Nominal flowrate 710 @ 4 bar
  • SAP number EGH800VS
  • Connection Grooved
  • Size 3″/DN80
  • Finish Body: Natural | Pipe: Flame red RAL3000
  • Main material Body: Stainless steel 316 | Pipe: Stainless steel 316
  • Style Fixed
  • Nominal flowrate 710 @ 4 bar
  • SAP number EGH800V
  • Connection Grooved
  • Size 3″/DN80
  • Finish Body: Natural | Pipe: Flame red RAL3000
  • Main material Body: Stainless steel 316 | Pipe: Carbon steel
  • Style Fixed
  • Nominal flowrate 710 @ 4 bar
SAP number Connection Size Finish Main material Style Nominal flowrate
EGH800D
Flange
3″/DN80
Body: Natural | Pipe: Flame red RAL3000
Body: Stainless steel 316 | Pipe: Carbon steel
Fixed
710 @ 4 bar
EGH800DS
Flange
3″/DN80
Body: Natural | Pipe: Flame red RAL3000
Body: Stainless steel 316 | Pipe: Stainless steel 316
Fixed
710 @ 4 bar
EGH800VS
Grooved
3″/DN80
Body: Natural | Pipe: Flame red RAL3000
Body: Stainless steel 316 | Pipe: Stainless steel 316
Fixed
710 @ 4 bar
EGH800V
Grooved
3″/DN80
Body: Natural | Pipe: Flame red RAL3000
Body: Stainless steel 316 | Pipe: Carbon steel
Fixed
710 @ 4 bar

Additional part numbers might be available. Please refer to the technical documentation or contact your local Viking sales office for more information.
